The new Syng Studio app for Mac is here to turn Cell Alpha into a reference system.
Turn any room into a spatial audio studio
Juan Mendez
@silentservant77
Jaroslav Beck
@jaroslavbeck
Mike Tucci
@miketuccimane
Michael Gaubert
@michaelgaubert
Engine Room Audio
@engineroomaudio
Damon Way
@damonway
It's the all-in-one professional studio for every creative, just ask Mike Tucci.
“Syng is changing the game with Cell Alpha and Triphonic audio. The Syng Studio setup saves me valuable time and money, and eliminates the headaches while delivering the best quality spatial sound out there... it’s a no brainer to me.”
Work out loud
No more silent studios. Syng Studio with Cell Alpha was created to ensure you can experience immersive, moving sound while you're creating immersive, moving sound.
Deep Smooth Bass
Each Cell Alpha is equipped with an integrated subwoofer consisting of two opposing drivers that can achieve 23Hz of pure bass you can feel. Increasing the number of Cells distributes the bass to provide insanely smooth coverage throughout the room.
More Channels Than Speakers
The Triphone is a circular array of three horns designed to steer mid and high frequencies with pinpoint accuracy. A single Cell Alpha can reproduce any channel count. The accuracy of increased channels improves with each additional unit in the configuration.
Perfect Timing
A three-way system with eight drivers, Cell Alpha emits sound from a single point so the full-frequency range reaches your ears simultaneously.
Cell Alpha Product Details
Audio
Frequency response: Smooth (±3 dB) from 23 Hz to 20 kHz
Two woofers in opposing force-balanced configuration
Three element, two-way beamforming array for precise control of directivity
Three microphones for automatic room equalization, wall proximity and orientation detection, and multi-Cell geometry calculation
Dynamic Range: the Cell can achieve film reference levels (85 dB SPL (C-weighted, slow) for –20 dBFS narrowband pink noise and a maximum level of 105 dB SPL (rms))
Connectivity
Airplay 2
Spotify Connect
Tidal Connect
USB Audio in with two USB-C ports at top and bottom for a clean wire setup
HDMI Enhanced Audio Return Channel (eARC) compatible with Syng Link cable
Control Ring
Volume control
Transport controls
Reset
Electrical and Environmental Requirements
Universal input 100 - 240 VAC, 50-60 Hz power supply
Operating temperature of 32° to 95° F (0° to 35° C)
Relative humidity 5% to 90% non-condensing
Box Contents
Cell Alpha
Power cable
Table Stand or Floor Stand
Assembly instructions
Syng Space App Compatibility
iOS 14.0 and higher
Android coming soon
Cell Alpha Dimensions & Weight (without stand)
Diameter: 11.8 inches (300 mm)
Height: 12 inches (304 mm)
Weight: 12.8 lbs (5.8 kg)
Cell Alpha with Table Stand Dimensions & Weight
Diameter/Width: 11.8 inches (300 mm)
Height: 17.2 inches (437 mm)
Weight: 18.52 lbs (8.4 kg)
Cell Alpha with Modular Floor Stand Dimensions & Weight
Diameter/Width: 11.8 inches (300 mm)
Lounge Height: 36.2 inches (919 mm)
Lounge Weight: 29.54 lbs (13.4 kg)
Studio Height: 48.4 inches (1230 mm)
Studio Weight: 30.2 lbs (13.7 kg)
The system is designed to grow with you and your needs. Utilizing Triphonic audio technology, Cell Alpha self-calibrates to optimize its performance in any number, in any space. With setup taking only minutes, start with one or expand your configuration up to five for the ultimate spatial experience.
for Home Creators
Unlock the full potential of your creativity with an instant spatial audio studio in any room.
for Professionals
Access the capabilities of mixing in spatial audio with a system that improves workflows and provides total independence while saving time and money.
for Studios
Modernize your audio referencing capabilities in every space for new shared experiences and workflows.
Let’s start mixing
Enjoy the performance and beauty of sound out loud and create your own spatial audio reference system. Install Syng Studio for Mac (Beta) to configure any number of Cells for multichannel mixing.
System Requirements
Quick Start Guide
